Description

The DXR15mkII achieves class-leading maximum SPL of 134dB and full bandwidth performance by combining a powerful Class-D amplifier with a high-power woofer and Yamaha’s cutting edge technologies. Throw in some D-CONTOUR and you’ll feel like you’re using a subwoofer.

General Features

• 15″ powered loudspeaker with 1100W Class-D amplifier
• Achieves high SPL output with remarkable clarity throughout its frequency response
• 1.75″ neodymium high-frequency compression driver and high-output 15″ woofer which combine for a wide frequency response with powerful bass
• Frequency Range: 49 Hz to 20 kHz
• Max SPL: 134 dB
• Precision 48-bit DSP processing for clear high-definition sound and built-in D-Contour intelligent dynamic control
• Durable and compact ABS enclosure
• Symmetrical Design for mirror-mode floor monitoring

Key Features

• FIR-X tuning
  • Proprietary sound-processing technology utilizing alinear-phase FIR filter delivers high-quality sound at highresolution with a smooth frequency response that isunaffected by phase interference near the crossover point
• D-CONTOUR (Dynamic CONTOUR)
  • D-CONTOUR is a multiband compressor that dynamicallycontrols the level of each frequency range according to theapplication and human hearing characteristics
    • FOH/MAIN: For use as a main speaker
    • MONITOR: Optimized for use as afloor monitor
• Mixing/LINK functionality
  • Features mixing functionality, enablingyou to mix sounds by directly inputting three channel signalsinto the unit
  • LINK function enables you to easily configurea stereo or dual-mono SR (Sound Reinforcement) systemusing two DXR mkIIs
• DSP-controlled advanced protectionsystem
  • Powerful protection circuits ensure secure protection in thespeaker unit, amplifier unit, and power supply unit
  • Protection functionality promotes optimal performance ofeach component and optimum reliability without distortioneven in challenging environments
