Description

B-Stock with Full Warranty
Return that may have slight traces of use.

Speaker for Ceiling Installation

• PhaseGuide technology
• Nominal horizontal dispersion angle of 180°
• High frequency compression driver
• 8″ Woofer supports boundary loading close to the wall
• 2-Way passive crossover with transformer for 70 V / 100 V audio systems
• Spring-loaded brackets with snap-in function
• Magnetically fixed grille
• Certified according to UL1480A for safe installation in ceilings
• Frequency response (+/- 3 dB): 50 Hz to 18 kHz
• Frequency range (-10 dB): 45 Hz to 20 kHz
• Nominal dispersion: 75° Vertical, 180° horizontal
• Continuous power rating: 125 W (500 W peak)
• Sensitivity (SPL / 1 W at 1 m): 93 dB SPL
• Max. SPL at 1 m: 114 dB SPL (120 dB SPL peak)
• Drivers: 1 x 20 cm woofer, 1 x compression driver
• Nominal impedance: 8 Ohm (transformer-bridged)
• Colour: White

30 30-Day Money-Back Guarantee

3 3-Year Thomann Warranty

• Available since August 2021

• Item number 526103

• Sales Unit 1 piece(s)

• Colour White

• Design square

• Type Fullrange

• Cut-out Diameter in mm 339 mm

• Mounting Depth in mm 249 mm

• Woofer in inch 8″

• IP Class No

• Power (Low Impedanz) 125 W

• Impedance in Ohms 8 Ohms

• 100V Transformer Yes

• 100V Taps (W) 80/40/20/10/5

• Outer Diameter in mm 390 mm

• Weight in kg 10,1 kg

• X-way 2-way
