Description

Emulating our heroes is one of the many things we can have fun with as musicians which is why Behringer wanted the SPRING REVERBERATION 636 to be as faithful as possible to the original Grampian Type 636 used by Pete Townshend and legendary reggae dub master Lee “Scratch” Perry. Now you can have their legendary secret ingredient added to your setup so you can create your very own masterpiece, or to just have fun with.

The 636 is a no-nonsense reverb unit. No digital emulation here. Inside, you’ll find dual mechanical springs that provide that lush and dynamic reverb sound that no other reverb type can match. And if you bump the 636 it can even do that iconic spring reverb “sproing.” Just be gentle with it.

Behringer have built the 636 to be as versatile as possible so you can use it with any instrument you want! The 636 accepts balanced and unbalanced mic inputs where you can control the input level with the Mic Channel knob as well as high- and low-level line inputs such as keyboards or guitars. The integrated overload circuit can even give you a warm analogue overdrive before the signal gets passed to the reverb.

Features

• Classic analogue spring reverb effect from the ‘60s for authentic reproduction of original Grampian Reverberation Unit Type 636 circuitry
• Legendary vintage reverb sound from the king of spring reverbs, as heard on countless records
• Dual mechanical springs provide signal reflections for rich and dynamic room emulations
• Overload circuit for a warm analog overdrive of the signal before entering the spring reverb

Specifications

• Inputs
  • 2x Balanced Microphone: 25 O 20 µv sensitivity
  • 2x Unbalanced Microphone: 25 O 20 µv sensitivity
  • 2x High Level Auxilliary: 1 MO 500 mv sensitivity
  • 2x Low Level Auxilliary: 50 kO 10 mv sensitivity
• Outputs
  • 2x Unbalanced line level
• Controls
  • Switches: Power (top panel)
  • Knobs:
    • Reverberate
    • Aux Channel
    • Mic Channel
    • Sockets
    • 2x Mute Footswitch
• Audio
  • Frequency Response: ±2dB 35Hz – 20kHz
  • Reverberation Delay: 29 – 37ms nominal
  • Reverberation Time: 2 seconds at 300Hz
  • Reverberation Response: ±3dB 100Hz – 6kHz
• Dimensions
  • 374mm x 135mm x 86mm
  • 72 hp when in Eurorack
  • 1.58kg
• Power Consumption: 1000mA 12V DC
